Mgo Rod coiling machine for cartridge heater DGRX01

Mgo Rod coiling machine for cartridge heater

is special used for cartridge heater, to wind the resistance wire around the MgO rod.

*step motor drive, the pitch is adjustable
*PLC control, easy to operate
*Stable performance, high production
*Easy to change the mould for different sizes of MgO rod.

Main technical parameter:

Voltage: single AC 220±10%,50Hz
Power: 300W
Diameter range: below 21mm
Length range: below 800mm
Dimension (L * W * H):1560*600*1220mm
Weight: 300kgs

Video of Mgo Rod coiling machine for cartridge heater
